Stepping Motor
| Stepper Lead Screw Linear Actuator | |
DINGS' Stepper Lead Screw Linear Actuator come in eight different frame size from 14mm [NEMA6] to 86mm [NEMA34]. There are four form factors as External, Non-Captive, Kaptive and Electric Cylinder (Captive). DINGS' provides over 20 different travels/step of lead screws ranging from 0.00006 inch [.0015mm] to .005 inch [.127mm]. Microstepping can be used for finer resolution and various step motor angle options are available. |  |
| Stepper Ball Screw Linear Actuator | |
| DINGS' Stepper Ball Screw Linear Actuator is avaiable for External from NEMA6 to NEMA23 sizes with various step resolutions from 0.005mm/step to 0.1mm/step. C7 ball screw is standard and C5 or C3 grade is optional. External type of Stepper Ball Screw Linear Actuator is standard and we also offer guide supported high precision linear actuator, DLG Series for 28 & 42mm stepper. View Details |  |
| PM Stepper Linear Actuator |  |
DINGS' Permanent Magnetic PM stepper linear actuators are available as 20/25/36mm sizes via External, Non-Captive and Kaptive especially for economic version of applications. | |
| Hybrid Rotary Stepper Motor |  |
| DINGS' provides 8 different sizes of hybrid stepper motors from 14mm to 86mm. Each size has multiple stack lengths. Single or dual shaft is standard but also customized shaft options are also available. In addition, various ratio of planetary gearboxes, encoders and power-off brakes are optional. View Details | |
| Hollow Shaft Stepper Motor |  |
| DINGS' provides standard and also customized hollow shaft motors from 14mm to 86mm sizes. View Details | |
| Brushless DC Motors |  |
| DINGS' provides 5 different sizes of Brushless DC motors from 16mm to 86mm. Hall sensor standard and also incremental encoder also can be optional for low voltage DC Servo market. From 9.2W to Max. 471.2W capacity of BLDCs are available. View Details | |
| Slotless Brushless DC Motor |  |
| DINGS' Slotless Brushless DC Motors can avoid the pulsation of air gap magnetic induction caused by uneven magnetic resistance in the teeth. It can eliminate the pulse loss in the armature core and the surface loss on the main pole surface. Slotless Brushless DC Motor has high durability, low electrical noise and high efficiency. Maximum efficiency of motor reaches 91% and this motor is suitable for the servo system which needs quick movement and high power. View Details | |
| Voice Coil Motor |  |
| DINGS' provides standard voice coil motors but also customized solutions are optional. View Details | |
| Motion Controller |  |
| DINGS' offers various drivers & controllers with our linear actuators and motors as one package. From standard mircostepping drivers, closed loop stepper electronics, open/closed loop dynamic drivers and up to BLDC/VCM/Stepper Multi-Purpose of EtherCAT & CANOpen drivers & controllers, we enable customer to easily choose appropriate solutions. View Details | |
| Customization Options |  |
| DINGS' offers various options to help customer for wide range of applications via encoders, brakes, gearboxes and other customization solutions for examples special coating and machining of screw, anti-backlash nut and hand-knob. View Details | |
| Gripper |  |
| Based on our own design and development of through motor foundation, the stroke of 6mm and 12mm Gripper can be selected. The structure is compact and simple, which can replace the pneumatic clamping claw, reduce the use noise, and effectively improve the accuracy. High resolution of encoder based closed loop torque control is optional. View Details | |
| DLM Series |  |
| Based on DINGS' platform products, high precision of lead screw linear actuator and self-developed simple linear module, DLM series is compact and reliable structure of linear solution.DLM Series is good precision, high diversity of optional stroke and lead based customization linear module which can provide customers with integrated customization solutions. View Details | |
